數位看板播放系統
SI-121-N
搭載Intel® Core® Processor N-系列處理器的入門款無風扇播放系統，支援Intel® Graphics built-in and One HDMI 2.0b
- iSMART intelligent energy-saving technology - enables power on/off scheduling and power resume functions
- Intel® Core® Processor N-Series (Twin Lake)
- 1x HDMI 2.0b with independent audio output
- HDMI-CEC and display monitoring functions
- Supports PDPC (Peripheral Device Power Control) function
- Supports OOB function via I210IT LAN port (optional)
- 1x DDR5-4800 SO-DIMM, Max. 32GB
- 1x M.2 M-Key (2280) for storage
- 1x M.2 B-Key (3052) for 5G/LTE
- 1x Nano SIM slot
- TPM 2.0 and watchdog timer
- Industrial-grade robust, fanless and compact design
SI-121-N 是一款輕巧型無風扇數位看板播放系統，採用僅 2.3 公分的纖薄機身設計，專為入門級顯示應用與空間受限的智慧零售場域打造，兼具穩定效能與高彈性建置能力，輕鬆建構全天候穩定運作的高效數位看板解決方案。
SI-121-N 搭載 Intel® Core™ Processor N 系列（Twin Lake）處理器，具備優異運算效能與流暢影音播放能力，透過 HDMI 輸出清晰細膩的4K高畫質影音內容，適用於零售、餐飲、交通運輸及公共資訊顯示等應用場域。其工業級無風扇與輕巧設計，不僅可無噪運作，更有效降低維護需求，確保全年無休的穩定運作能力。
為提升系統管理效率，SI-121-N 支援 iSMART 智慧控制與節能技術、HDMI-CEC 與顯示監控功能，提供更直覺且高效的智慧化控制能力。系統同時具備彈性擴充設計，支援 M.2 儲存裝置，並可選配 5G/LTE 無線通訊模組，滿足多元應用與建置需求。結合穩定效能、可靠設計與易於整合的特性，SI-121-N 為數位看板應用提供兼具實用性與擴充性的理想選擇，協助客戶快速建置並加速應用落地。
SI-212-N 產品特色:
- Intel® Core™ Processor N 系列（Twin Lake): 提供高效能運算，確保數位看板內容流暢播放
- 單一 HDMI 輸出，支援 4K 顯示: 呈現清晰細膩的高畫質影音內容
- 輕巧型無風扇設計
靜音運作: 提升系統穩定性並降低維護需求
- 智慧電源與顯示控制: 支援 iSMART、HDMI-CEC 與顯示監控，管理更便利
- 彈性擴充能力:
支援 M.2 儲存與選配 5G/LTE，滿足多元應用需求
| System Mainboard | MBD121 |
| CPU | Intel® N-Series (Twin Lake) Processors |
| CPU Socket | FCBGA1264 |
| Chipset | Integrated |
| Memory | 1x SO-DIMM DDR5 4800 MHz, Max. 32GB |
| Graphics | Intel® Graphics |
| LAN | 1x 1.0 Gb LAN with optional OOB/In-band optional function support |
| Expansion Slots | 1x M.2 M-key (2280) for storage 1x M.2 B-key (3052) for 5G/LTE 1x SIM card slot |
| I/O Interface | 1 x HDMI 2.0b 2x USB 3.2 (with 1x PDPC function included) 1x RJ45 for Gigabit LAN 1x RJ45 for RS-232 serial port 1x Audio connector for Line-out 1x Power Button 1x Power Jack (+12V DC) 2x LED for Power & Storage |
| Auto Control and Monitoring | Watchdog Timer: 256 segments, 0, 1, 2…255 (sec / min) |
| Power Requirement | +12V DC |
| Construction | Aluminum + SGCC |
| Weight | 1.0 kg (2.2 lbs) |
| Chassis Color | Black & White |
| Storage | 1x M.2 M-key (2280) (NVMe / SATA) |
| Power Supply | 50W power adaptor |
| Mounting | Standard system bracket |
| Dimensions | 170mm(W) x 123mm(D) x 22.5mm(H) |
| Operating Temperature | 0°C~ 45°C (32°F~113°F) |
| Storage Temperature | -20° ~ 80°C (-4°F~176°F) |
| Relative Humidity | 10%~90% (non-condensing) |
| Vibration | 1Grms/3~500Hz/ Random operation |
| Certification | CE, FCC Class B, cULus |
| Operating System | Windows 11 IoT Enterprise LTSC Linux Ubuntu 64-bit |
| SI-121-N355TB | Intel® Core™ 3 Processor N355, 1x 8GB DDR5 5600 SO-DIMM memory, 1x M.2 256GB and 50W power adapter, with TPM, OOB function |
| SI-121-N150TB | Intel® Processor N150, 1x 8GB DDR5 5600 SO-DIMM memory, 1x M.2 256GB and 50W power adapter, with TPM, OOB function |
| SI-121-N355T | Intel® Core™ 3 Processor N355, 1x 8GB DDR5 5600 SO-DIMM memory, 1x M.2 256GB and 50W power adapter, with TPM |
| SI-121-N150T | Intel® Processor N150, 1x 8GB DDR5 5600 SO-DIMM memory, 1x M.2 256GB and 50W power adapter, with TPM |
| SI-121-N355 | Intel® Core™ 3 Processor N355, 1x 8GB DDR5 5600 SO-DIMM memory, 1x M.2 256GB and 50W power adapter |
| SI-121-N150 | Intel® Processor N150, 1x 8GB DDR5 5600 SO-DIMM memory, 1x M.2 256GB and 50W power adapter |
| SI-121-N355B | Intel® Core™ 3 Processor N355, 1x 8GB DDR5 5600 SO-DIMM memory, 1x M.2 256GB and 50W power adapter, with OOB function |
| SI-121-N150B | Intel® Processor N150, 1x 8GB DDR5 5600 SO-DIMM memory, 1x M.2 256GB and 50W power adapter, with OOB function |
| 產品資料表 | SI-121-N |
