嵌入式边缘运算系统

ASB200-962U

AI边缘运算计算机系统-搭载Intel® Core™ Ultra 100U系列处理器

  • Onboard Intel® Core™ Ultra 100U Series mobile Processors (TDP@15W)
  • Multiple M.2 sockets (B-Key/ E-Key and M-Key)
  • 2x DDR5-5600 SO-DIMM, Max. 96GB
  • Dual 2.5G LAN, 3x USB 3.2, 3x USB 2.0, 1x COM
  • Supports 2.5 SSD & M.2 NVMe storage devices
  • Supports HDMI & DP, External GPIO, TPM(2.0)
  • Supports operating temperature from -10°C to +55°C
  • Optional VESA mount bracket
  • Fanless
  • 5G
  • AI Solution

ASB200-962U是一款专为高效能、稳定可靠的AI边缘运算需求量身打造的轻巧型无风扇边缘电脑。 其搭载Intel® Core™ Ultra 100U系列处理器,整合AI加速能力,可在效能、低功耗与空间效率之间取得最佳平衡。 无论是智能制造、零售自动化或各类工业与商用边缘应用,ASB200-962U都能让AI在现场实时运作、稳定发挥。


The ASB200-962U is a compact fanless edge AI computer designed to meet the growing demand for efficient and reliable AI inference at the edge. Powered by Intel® Core™ Ultra 100U Series processors with integrated AI acceleration, the ASB200-962U delivers a balanced combination of computing performance, power efficiency, and compact design for industrial and commercial edge applications.


The ASB200-962U is a compact fanless edge AI computer designed to meet the growing demand for efficient and reliable AI inference at the edge. Powered by Intel® Core™ Ultra 100U Series processors with integrated AI acceleration, the ASB200-962U delivers a balanced combination of computing performance, power efficiency, and compact design for industrial and commercial edge applications.


The ASB200-962U supports up to 96GB DDR5 memory and offers rich I/O connectivity to enable seamless integration with cameras, sensors, and peripheral devices. With multiple M.2 expansion slots, the system allows flexible configuration for NVMe storage, wireless connectivity such as WiFi or 5G, and optional AI acceleration modules, making it adaptable to a wide range of deployment requirements.


Designed for demanding edge and AIoT applications, the ASB200-962U features a fanless thermal architecture that delivers quiet, maintenance-free operation and long-term reliability. Its compact footprint and low power consumption enable flexible deployment in space-constrained environments, making it ideal for smart manufacturing, retail automation, and intelligent transportation. Optimized for real-time analytics, intelligent automation, and machine vision, the ASB200-962U empowers system integrators to accelerate AI-driven innovation and unlock smarter edge applications with confidence.

System Mainboard IB962AF-165U/ IB962AF-135U
CPU Type Intel® Core™ Ultra 100U Series Mobile Processors
System Speed Up to 4.9GHz
AI Inference Computing Power 12 pTOPS
Front Panel External I/O 3x USB 3.2
1x USB 2.0
1x DisplayPort
1x HDMI
1x DB9 for COM#1 (RS232/422/485)
2x 2.5G LAN
Rear Panel External I/O 1x power button
1x Digital I/O (4-in/4-out)
2x Antenna holes
1x HDD LED
1x 3-pin DC-in terminal block for 24V power adaptor
Expansion Slot 3x M.2 sockets (B-Key/ E-Key and M-Key)
Storage 1x M.2 (M2280), (supports NVMe)
1x 2.5’’ HDD or SSD
Power Requirement 24V DC IN
Power Supply 90W power adaptor
Construction Aluminum & steel
Chassis Color Black
Mounting Desktop & wall mount bracket
Optional VESA mount kit
Weight 1.5 kg
Dimensions 180mm (W) x 150mm (D) x 72mm (H)
7.08” (W) x 5.9” (D) x 2.83” (H)
Operating Temperature -10°C ~ +55°C (14°F~131°F)
*with airflow 0.9m/s
Storage Temperature -20°C ~ +80°C (-4°F~176°F)
Relative Humidity 5% ~ 90% @ 45°C (non-condensing)
Vibration Operating: 1Grms / 3~500Hz
Shock Operating : 20G / 11ms
Non-operating : 40G / 11ms
Certification CE/LVD/FCC Class B
Operating System Windows 11
ASB200-962U-7M Fanless chassis with IB962AF-165U, Intel® Core™ Ultra7 CPU(TDP@15W), w/ 1x COM, 2x DDR5 memory slot, desktop stand & mounting bracket, w/o memory/ 90W power adaptor and VESA mount bracket
ASB200-962U-5M Fanless chassis with IB962AF-135U, Intel® Core™ Ultra5 CPU(TDP@15W), w/ 1x COM, 2x DDR5 memory slot, desktop stand & mounting bracket, w/o memory/ 90W power adaptor and VESA mount bracket
90W power adaptor (optional) 90W (24V@3.75A) power adaptor, bare wire-type compatible with IEC62368-1/EN62368-1 [PN: A005PS090W0100710P]
Optional Accessories VESA mount kit [PN: SC2ASB2----0A1200R] Wifi antenna kit [PN: A024MDWIFI0042400P (Intel® 9260) + SC2WIFI----A10M00R (WiFi Kit)]
产品数据表 ASB200-962U
使用手册 ASB200-962U V1.0
产品型录 AI Computing Platform (Vol.25.12)
驱动程序 - 系统 ASB200-962U Driver DVD
