数字广告牌播放系统
SI-121-N
搭载Intel® Core® Processor N-系列处理器入门款无风扇播放系统，支持Intel® Graphics built-in and One HDMI 2.0b
- iSMART intelligent energy-saving technology - enables power on/off scheduling and power resume functions
- Intel® Core® Processor N-Series (Twin Lake)
- 1x HDMI 2.0b with independent audio output
- HDMI-CEC and display monitoring functions
- Supports PDPC (Peripheral Device Power Control) function
- Supports OOB function via I210IT LAN port (optional)
- 1x DDR5-4800 SO-DIMM, Max. 32GB
- 1x M.2 M-Key (2280) for storage
- 1x M.2 B-Key (3052) for 5G/LTE
- 1x Nano SIM slot
- TPM 2.0 and watchdog timer
- Industrial-grade robust, fanless and compact design
SI-121-N 是一款轻巧型无风扇数字广告牌播放系统，采用仅2.3厘米的纤薄机身设计，专为入门级显示应用与空间受限的智慧零售场域打造，兼具稳定效能与高弹性建置能力，轻松建构全天候稳定运作的高效数字广告牌解决方案。
SI-121-N 搭载Intel® Core™ Processor N系列（Twin Lake）处理器，具备优异运算效能与流畅影音播放能力，透过 HDMI 输出清晰细腻的4K高画质影音内容，适用于零售、餐饮、交通运输及公共信息显示等应用场域。 其工业级无风扇与轻巧设计，不仅可无噪运作，更有效降低维护需求，确保全年无休的稳定运作能力。
为提升系统管理效率，SI-121-N 支持iSMART智能控制与节能技术、HDMI-CEC与显示监控功能，提供更直觉且高效的智能化控制能力。 系统同时具备弹性扩充设计，支持M.2存储装置，并可选配5G/LTE无线通信模块，满足多元应用与建置需求。 结合稳定效能、可靠设计与易于整合的特性，SI-121-N 为数字广告牌应用提供兼具实用性与扩充性的理想选择，协助客户快速建置并加速应用落地。
SI-212-N 产品特色:
- Intel® Core™ Processor N 系列（Twin Lake): 提供高效能运算，确保数字广告牌内容流畅播放
- 单一 HDMI 输出，支持 4K 显示: 呈现清晰细腻的高画质影音内容
- 轻巧型无风扇设计: 静音运作，提升系统稳定性并降低维护需求
- 智能电源与显示控制: 支持 iSMART、HDMI-CEC 与显示监控，管理更便利
- 弹性扩充能力: 支持 M.2 储存与选配 5G/LTE，满足多元应用需求
| System Mainboard | MBD121 |
| CPU | Intel® N-Series (Twin Lake) Processors |
| CPU Socket | FCBGA1264 |
| Chipset | Integrated |
| Memory | 1x SO-DIMM DDR5 4800 MHz, Max. 32GB |
| Graphics | Intel® Graphics |
| LAN | 1x 1.0 Gb LAN with optional OOB/In-band optional function support |
| Expansion Slots | 1x M.2 M-key (2280) for storage 1x M.2 B-key (3052) for 5G/LTE 1x SIM card slot |
| I/O Interface | 1 x HDMI 2.0b 2x USB 3.2 (with 1x PDPC function included) 1x RJ45 for Gigabit LAN 1x RJ45 for RS-232 serial port 1x Audio connector for Line-out 1x Power Button 1x Power Jack (+12V DC) 2x LED for Power & Storage |
| Auto Control and Monitoring | Watchdog Timer: 256 segments, 0, 1, 2…255 (sec / min) |
| Power Requirement | +12V DC |
| Construction | Aluminum + SGCC |
| Weight | 1.0 kg (2.2 lbs) |
| Chassis Color | Black & White |
| Storage | 1x M.2 M-key (2280) (NVMe / SATA) |
| Power Supply | 50W power adaptor |
| Mounting | Standard system bracket |
| Dimensions | 170mm(W) x 123mm(D) x 22.5mm(H) |
| Operating Temperature | 0°C~ 45°C (32°F~113°F) |
| Storage Temperature | -20° ~ 80°C (-4°F~176°F) |
| Relative Humidity | 10%~90% (non-condensing) |
| Vibration | 1Grms/3~500Hz/ Random operation |
| Certification | CE, FCC Class B, cULus |
| Operating System | Windows 11 IoT Enterprise LTSC Linux Ubuntu 64-bit |
| SI-121-N355TB | Intel® Core™ 3 Processor N355, 1x 8GB DDR5 5600 SO-DIMM memory, 1x M.2 256GB and 50W power adapter, with TPM, OOB function |
| SI-121-N150TB | Intel® Processor N150, 1x 8GB DDR5 5600 SO-DIMM memory, 1x M.2 256GB and 50W power adapter, with TPM, OOB function |
| SI-121-N355T | Intel® Core™ 3 Processor N355, 1x 8GB DDR5 5600 SO-DIMM memory, 1x M.2 256GB and 50W power adapter, with TPM |
| SI-121-N150T | Intel® Processor N150, 1x 8GB DDR5 5600 SO-DIMM memory, 1x M.2 256GB and 50W power adapter, with TPM |
| SI-121-N355 | Intel® Core™ 3 Processor N355, 1x 8GB DDR5 5600 SO-DIMM memory, 1x M.2 256GB and 50W power adapter |
| SI-121-N150 | Intel® Processor N150, 1x 8GB DDR5 5600 SO-DIMM memory, 1x M.2 256GB and 50W power adapter |
| SI-121-N355B | Intel® Core™ 3 Processor N355, 1x 8GB DDR5 5600 SO-DIMM memory, 1x M.2 256GB and 50W power adapter, with OOB function |
| SI-121-N150B | Intel® Processor N150, 1x 8GB DDR5 5600 SO-DIMM memory, 1x M.2 256GB and 50W power adapter, with OOB function |
| 产品数据表 | SI-121-N |
